LCL Canopy Light

TECHNICAL DATA

SPECIFICATIONS

Rated Voltage (V): AC100-277V Luminaire Efficacy(lm/W): 140lm/W
Frequency (Hz): 50/60Hz LED Type: SMD 3030, Phillips
Power Consump on (W): 80W | 100W | 120W | 150W | 180W LED Quan ty: 210pcs LED
200W | 240W L&B Ra ng @ 50 000hrs: L80 B10
Colour Rendering (CRI): 70 Ingress Protec on(IP): IP65
Correlated colour Temp (CCT): 3000K - 5700K Beam Angle: 120°
Total Harmonic Distor ons (THD): <20% Moun ng Op ons: Surface
Power Factor (PF): >0.90 Recessed
Opera ng Temp: -35°C~55°C) Entry Cable: Top
Driver Type: UL/cUL, Class II Electrical Class: Class I
Humidity: 20%~85%, non condensing

MATERIAL STRUCTURE
Housing Body: Aluminium Die Cas ng Housing Colour: White
Lens Diffuser: Tempered Glass Lens: Clear
OPTIONAL FEATURES
Dimming & Mo on Op ons: Dim or Microwave sensors (On Request)
Cer fica ons CE/RoHs/IEC/SANS

ORDERING INFORMATION

XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX

Product Family Product ID Size(mm) Power Efficency CCT IP Beam Angle Surge Moun ng Driver Control Type CRI

Canopy LCL 420*420*67 80W 140lm/W 2700K(27) IP65 120° 4KV Surface Standard Dim (DIM) 70 (7)
(CAN) (LCL) (446) (80W) (140LPW) 3000K(03) (IP65) (120DEG) (4KV) (SUR) (STD) Non Dim (NDIM)
6kg 100W 3500K(35) 6KV Recessed
(100W) 4000K(04) (6KV) (REC)
120W
(120W) 4500K(45)
420*420*67 150W 5000K(05)
(446) (150W) 5700K(57)
6.5kg 6000K(06)
540*540*67 180W 6700K(67)
(556) (180W)
6.5kg
540*540*67 200W
(556) (200W)
7.5kg
540*540*67 240W
(556) (240W)
8kg
