MAX Bulkhead

SPECIFICATIONS

Rated Voltage (V): AC100-277V Luminaire Efficacy(lm/W): 120(lm/W) (F and D Series)
Frequency (Hz): 50/60Hz 210(lm/W) (F Series)
Power Consump on (W): 40W - 120W L&B Ra ng: L80 B10 50 000hrs
Correlated color Temp (CCT): 3000K- 4000K- 6000K L70 B10 100 000hrs
Colour Rendering (CRI): >70Ra (>80Ra) Ingress Protec on(IP): IP65
Total Harmonic Distor ons (THD): <15% Ingress Protec on(IP): IK08 (Glass Cover)
Power Factor (PF): >0.97 IK09 (PC Cover)
Electrical Class: EU Class I Beam Angle: 120°
LED Type: SMD 3030 Lifespan: 50 000hrs
Driver Type: Tridonic/Osram/Phillips/Vossloh Schwabe/Meanwell SDCM: <3
Opera ng Temp: -20°C ~ +45°C Moun ng Op ons: Surface Mount

Surge Protec on:
Cable Entry: Side

MATERIAL STRUCTURE

Housing Body: ADC12 Aluminium Housing Colour: Silver / Black
Lens Diffuser: Polycarbonate (PC) , Tempered Glass Op onal Coa ng: C5-M
OPTIONAL FEATURES

Dimmable Op ons: 0-10V
Sensor Op ons: Microwave
Emergency Op ons: 1 - 2Hour @ 20% Back-up Power
ORDERING INFORMATION - 120LM/W F SERIES

XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX

Product Product Size(mm) Power Luminous CCT Ingress Beam Surge Moun ng Driver Control CRI Colour
Family ID (W) Efficacy Protec on Angle Protec on Kit Type

Bulkhead Max F PC 348*216*129 40W(40W) 120lm/W 3000K(03) IP65 120° 2.5KV Surface Standard Standard 70 (7) Silver
(BUL) (MAX-F/PC) (321) 60W(60W) (120LPW) 4000K(04) (IP65) (120D) (2.5KV) (SURK) (STD) STD) 80 (8) (SIL)
3kg 80W(80W) 6000K(06) 4KV 0-10V Emergency Black
(4KV) (DIM) (EMG) (BLK)
386*271*129 100W 6KV Microwave
(381) (100W) (6KV) (MIC)
5kg 120W
Max F Glass
(MAX-F/G) (120W)

Disclaimer
Due to the rapid development in LED technology the performance values, product specifica ons stated above are subject to change without prior no ce. Please note that images used may serve as illustra on purposes only. For
any requirements not covered in the above varia ons please contact ALTSA for a customized ligh ng solu on.
