Pelican Series

TECHNICAL DATA

SPECIFICATIONS
Rated Voltage (V): AC110-266V Luminaire Efficiency: 80lm/W
Frequency (Hz): 50/60Hz
Power Consump on (W): 36W 48W 60W 72W
Correlated color Temp (CCT): 2200K - 6000K
Colour Rendering (CRI): 80/90 Unified Glare Index(UGR): UGR22
Total Harmonic Distor ons (THD): <15% L&B Ra ng: L80 B10 50 000hrs
Power Factor (PF): >0.95 L70 B10 100 000hrs
Electrical Class: Class I
Opera ng Temp: -20 ~ +50°C Ingress Protec on(IP): IP20
Uniformity: 0.85 Beam Angle: 110°
Driver Type: Standard Lifespan: 50 000hrs-100 000hrs
LED Brand: SMD - HONGLI 2835 Moun ng Op ons: Suspended
SDCM: 4
Entry & Output Cable: Back / 20cm (Standard)

MATERIAL STRUCTURE
Housing Body: Aluminium Housing Colour: White/Black/Grey
Lens: Clear
Lens Diffuser: Poly Methyl Methacrylate(PMMA)

OPTIONAL FEATURES
Dimmable Op ons: DALI-Dimmable 0-10V Triac Dimmable
Sensor Op ons: Microwave Bi-Level
Emergency Op ons: 20% Back-up Power Built in
Cer fica ons RoHs/IEC/SANS

ORDERING INFORMATION

XXX XXX XXXX XXX XXX XXX XXX XXX X

Product Family Product ID Size & Weight Power Efficency Driver Type Control Type CRI GLARE RATE

Pendant ALTSA 400x20(042) 36W (0036) 80lm/W (80) Standard (STD) Standard (STD) 80 (8) 22 (22)
(PEN) Pelican Series 3.2kg Emergency (EMG) 90 (9)
(APS)
600x20(062) 48W (0048) Microwave (MIC)
5kg
800x20(082) 60W (0060) Bi-Level(BIL)
6,5kg Dali (DAL)
1000x20(0102) 72W (0072) 0-10V (DIM)
8kg
Triac (TRI)
