Page 341 - ALTSA 2025 A & B Catalogue - Version 4P Final.cdr

Discovery Bulkhead

SPECIFICATIONS
Rated Voltage (V): 100-277V Luminaire Efficacy(lm/W): 100(lm/W) - 130(lm/W)
Frequency (Hz): 50/60Hz
Power Consump on (W): 18W , 32W Impact Protec on (IK): IK10
Colour Rendering (CRI): ≥ 70 / ≥ 80 Ingress Protec on(IP): IP66
Power Factor (PF): >0.95
Total Harmonic Distor ons (THD): <15% Beam Angle Symmetrical: 110°
Opera ng Temp: -25°C + 50°C
Surge Protec on:
Electrical Class: Class I L&B Ra ng: L90 B10
Driver Type: Meanwell Lifespan: 50 000hrs
LED Type: SMD Unified Glare Index(UGR): >UGR19
Correlated Coluor Temp(CCT): 3000K - 4000K - 6000K

Moun ng Op ons: Surface Mount

MATERIAL STRUCTURE
Housing Body: Marine Grade Chromated Aluminium Housing Finish: Black
Powder Coated
Lens Op cs: Polycarbonate (PC)

OPTIONAL FEATURES
Dimmable Op ons: DALI-Dimmable 0-10V
Sensor Op ons: Microwave Mo on
Emergency Op ons: EMG @ 1.5hrs, 2hrs

ORDERING INFORMATION

XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX X

Product Family Product ID Size Power Efficency CCT IP Beam Angle Surge Accessorie Driver Control Type CRI Colour

Bulkhead Discovery 298x191x108 18W(18W) 100lm/W 3000K(03) IP66 110° 4KV Light Shield Meanwell Standard (STD) 70 (7) Black (BLK)
(BUL) Bulkhead (211) 32W(32W) (100LPW) 4000K(04) (IP66) (110) (4KV) (LIS) (MNW) Emergency (EMG) 80 (8)
(DIS) 3.2kg 120lm/W 6000K(06) 6KV Microwave (MIC)
(120LPW) (6KV) Dali (DAL)
130lm/W 10KV 0-10V (DIM)
(130LPW) (10KV)
