Rhino H Floodlight

SPECIFICATIONS

Power Consump on(W) : 35-60W 80-120W 150-180W 200-240W 300W
Luminous Flux(lm) : 5400-10800LM 14400-21600LM 27000-32400LM 36000-43200LM 48000LMLM
Power Consump on(W) : 400W 500W 600-750W 800-1200W
Luminous Flux(lm) : 72000LM 80000LM 120000LM 160000LM

Input Voltage (V): AC100-277VAC Luminaire Efficacy(lm/W): 130(lm/W) - 200(lm/W)
Frequency (Hz): 50/60Hz
Correlated color Temp (CCT): 2700K - 6000K L&B Ra ng: L80 B10 50 000hrs
Colour Rendering (CRI): >70 L70 B10 100 000hrs
Total Harmonic Distor ons (THD): <15% Beam Angle: 15°|30°|60°|90°|P6
Power Factor (PF): >0.95
Opera ng Temp: -20°C ~ +45°C Ingress Protec on(IP): IP66
LED Type: SMD 3030 Impact Resistance (IK): IK08
Driver Type & Efficiency : SZ Driver | >95% SDCM: <5
Surge Protec on (KV): 6KV - Open Circuit Protec on Cer ficate: RoHS | CE | IEC

MATERIAL STRUCTURE

Housing Body: Die Cas ng ADC12 Aluminium Housing Colour: Silver
Lens Diffuser: Polycarbonate (PC) An Corrosion Coa ng: On Request

OPTIONAL FEATURES
Dimmable Op ons: DALI-Dimmable 0-10V Zigbee / Day & Night
Sensor Op ons: Microwave Mo on

PRODUCT SERIES

35-60W 80-120W 150-180W 200-240W 300W 400W 500W 600-750W 800-1200W
